| 型号/type | 处理量/processing capacity Nm3/min | 空气接管口径/air connection port caliber | 高/H(mm) | 直径/D(mm) | 重量G(KG) |
|---|---|---|---|---|---|
| HR-007 | 0.7 | ¾” | 260 | 80 | 0.9 |
| HR-015 | 1.5 | ¾” | 260 | 80 | 0.9 |
| HR-024 | 2.5 | 1½” | 330 | 100 | 1.5 |
| HR-035 | 3.8 | 1½” | 330 | 100 | 1.5 |
| HR-060 | 6.9 | 2½” | 430 | 100 | 2 |
| HR-090 | 9 | 2½” | 530 | 150 | 7.6 |
| HR-120 | 12 | 2½” | 900 | 150 | 12.9 |
| HR-150 | 15 | 2½” | 900 | 150 | 13 |
| HR-180 | 18 | 2½” | 900 | 150 | 13 |
| HR-240 | 24 | DN80 | 1190 | 310 | 27 |
| HR-300 | 30 | DN80 | 1100 | 420 | 60 |
| HR-360 | 36 | DN100 | 1150 | 420 | 65 |
| HR-450 | 45 | DN100 | 1230 | 459 | 80 |
| HR-500 | 50 | DN100 | 1130 | 513 | 115 |
| HR-600 | 60 | DN100 | 1155 | 565 | 130 |
| HR-750 | 75 | DN125 | 1210 | 657 | 140 |
| HR-900 | 90 | DN150 | 1210 | 657 | 145 |
| HR-1200 | 120 | DN200 | 1340 | 706 | 180 |
| HR-1500 | 150 | DN200 | 1340 | 706 | 190 |
| HR-1800 | 180 | DN200 | 1365 | 746 | 195 |
| HR-2100 | 210 | DN200 | 1365 | 746 | 196 |
| HR-3000 | 300 | DN250 | 1530 | 896 | 354 |
| HR-3600 | 360 | DN250 | 1660 | 946 | 398 |
| 等级/level | Q级精密过滤器/Q-Class Precision Filter | P级精密过滤器/P-Class Precision Filter | S级精密过滤器/S-Class Precision Filter | C级精密过滤器/C-Class Precision Filter |
| 材质/material | Multilayer Glass Fiber Filter Cartridge | Multilayer Glass Fiber Filter Cartridge | Multilayer Glass Fiber Filter Cartridge | Activated Carbon Filter Cartridge |
| 含油量/oil content | ≤5PPM | ≤0.1PPM | ≤0.01PPM | ≤0.003PPM |
| 杂质粒径/Particle Size of Impurities | ≤5Micron | ≤1Micron | ≤0.01Micron | —— |
| 最高使用温度/Maximum operating temperature | 120℃ | 120℃ | 120℃ | 30℃ |
| 功用/function | Airborne oil and dust are initially filtered to alleviate the burden on downstream filtration stages, thereby extending the service life of subsequent filters. | Air is purified to reduce oil content to an ultra-low concentration (0.1 PPM) while removing dust particles smaller than 1 micron. |
Airborne oil and dust are removed to comply with stringent precision industry standards, achieving an oil content reduction to 0.01 PPM and eliminating particulate contaminants down to sub-0.1-micron levels. |
Air passes through an activated carbon filter element for odor elimination and reduction of oil content to 0.003 PPM. |
– We deliver comprehensive solutions for compressed air quality and industrial gas requirements, including advanced filtering equipment and tailored air quality services.
– We’re here to help! Share your air quality needs, and we’ll design the optimal system tailored just for you.
Need guidance on choosing the right compressed air dryer? We’re here to tailor a solution that fits your needs perfectly.
Can meet any special dew point requirements and meet industry standards.
Models available for OEM custom.
Provide European ISO certification.
